Product Parameter
| Model | LC1KS | |
|
Capacity (VA/W)
|
1KVA/900W
|
|
|
Topology
|
Single Phase Input Single Phase Output
|
|
|
Mains Input
|
Wiring
|
1 Phase 3 Wires(L/N+PE)
|
|
Rated Voltage
|
110/115/120/127VAC
|
|
|
Voltage Range
|
Line-Neutral: 55~145VAC
|
|
|
Frequency Range
|
40Hz-70Hz
|
|
|
Input Power Factor
|
≥0.99
|
|
|
AC Output
|
Wiring
|
1 Phase L/N+PE
|
|
Output Voltage
|
110/115/120/127VAC
|
|
|
Voltage Regulation
|
±2%
|
|
|
Output Frequency
|
50/60±4Hz(Sync Mode) / 50/60Hz±0.1%(Free Run)
|
|
|
Waveform
|
Pure Sine Wave
|
|
|
Distortion (THDV%)
|
<2%(Linear Load)
<7%(None-Linear Load)
|
|
|
Overload capability
|
1Min@105%~125%Rated Load
30Sec.@125%~150%Rated Load
0.5Sec.@>150%Rated Load
|
|
|
Efficiency
|
AC/AC Mode
|
88%
|
|
DC/AC Mode
|
85%
|
|
|
Battery&Charge
|
Rated Battery Voltage
|
36VDC External
|
|
Battery Capacity
|
External Battery Depends
|
|
|
Backup Time
|
>6mins @Half Load
|
|
|
Charging Current
|
Standard Model with Internal Battery:1A
Long Backup Time Model :4A
|
|
|
Physica
|
Dimension
|
145*220*250mm
|
|
Weight (kg)
|
3.5
|
|
|
HMI
|
LCD Display
|
Input Mains Voltage, Frequency, Load level, Operation Mode, Health Status
|
|
Standards Communication Interface
|
1. RS232 PORT
|
|
|
Optional Extension Card
|
2. SNMP Card: Support remote monitor the UPS via Smart Phone APP, Web page, PC Monitor Software , Support Server / NAS shutdown
3.MODBUS Card
4.USB Card
5.Relay Card (Needs assembly according to order request before shipping)
|
|
|
Operating
Environment
Endurance
|
Temperature range
|
-10~50℃
|
|
Relative Humidity
|
0-98%（Non-condensing）
|
|
|
Acoustics Noise
|
<55dB @ 1 meters
|
|
Product Features
● Zero transfer time
True Double Conversion Online UPS, Provide most comprehensive protect mission critical equipment from wide range power quality issues
● DSP based digital control
Advance DSP base digital control bring high performance of high input Power factor, low distortion , supply the load with perfect sine wave AC power supply
●Ultra wide input mains range
Strong compatible with ultra with electric environment, stay well with ultra wide range mains of 90V~300V, 40~70Hz ,dramatically reduce battery discharge , prolong battery life.
●Best loading capability
Up to 0.9 Output Power Factor , 50/60 Hz Automatically adapting , Selectable voltage , perfectly match all kind of application
●Compatible with Genset
Capable of work with wide range of Getset, isolate fluctuation and noise from Genset , provide stable and clean power supply to the user equipment.
●High input power factor
Thanks to digital controlled PFC Technology, >0.99 input power factor, effectively avoid power pollution , save energy expense for customer
Soyan Advantages
Soyan is a professional UPS manufacturer, able to provide customers with different sizes, power, models and configurations of tower and rack online UPS products and excellent service, so that users can obtain the most suitable power solutions.
●Flexible customization service
Customize Online UPS of different sizes, power, models and configurations according to their own needs, so that the power solution is more in line with the actual needs. At the same time, our factory production mode is flexible, according to the market demand at any time to adjust the program.
●Efficient production capacity
Soyan through independent R&D and production, improve the efficiency and stability of product manufacturing, product performance is superior, reliable quality.
●Strong technical support
According to customer needs, Soyan provides one-to-one customized services, in the pre-sale, sale, after-sales links can provide strong technical support for customers.
